Chapter 7
Creating and Editing a Program File
7–10
5. Enter the address for the first examine if closed instruction. Type the
address I:1/0 , then press [ENTER] , then [F5] , ACCEPT. The following
display appears with the cursor positioned on the right power rail:
<
END
>
F1 F2 F3 F4 F5
>
2.1.0.0.*
OFL
] [ ( )
I I ] [
] [ ( ) ]/[ ( ) L ( ) U
6. Enter the output energize instruction. Press [F3] , —( )— . The
following zoom display appears:
ENTER BIT ADDR:
ZOOM on OTE
NAME: OUTPUT
ENERGIZE
BIT ADDR:
F1 F2 F3 F4 F5
2.0.0.0.* ( )
7. Type the address O:3/1 , then press [ENTER] , then [F5] , ACCEPT. The
cursor is now positioned on the output energize instruction and the
following display appears:
Notice that with the cursor placed
on the output instruction, the
instruction mnemonic and
address are displayed in the
upper left corner.
The cursor location is also
displayed in the upper right
corner. This indicates that the
cursor is located in program file
2, rung 1, nest level 0, branch
level 0 and on the second
instruction in the rung.
<
END
>
F1 F2 F3 F4 F5
>
2.1.0.0.2
OFL
] [ ( )
I I ] [
] [ ( ) ]/[ ( ) L ( ) U
( )
OTE:O0:3.0/1 NO FORCE
