Chapter 7
Creating and Editing a Program File
7–26
8. To enter the output energize instruction, press [F1] , INS_INST, then
[F1] , BIT, then [F3] , —( )— .
9. In the zoom display, type the address O:3/2 , then [ENTER] , and [ACCEPT] .
The display appears as follows:
I I
I I
I
I I
I
F1 F2 F3 F4 F5
2.1.1.1.7
] [ ( )
] [
] [ ( )
] [
] [
]/[
] [
( )
> ] [ ]/[ ( ) ( ) L ( ) U ( ) ( )
OFL
10. Press [ESC] twice to return to the proper menu. Then press
[F5] , ACP_RNG.
11. Save the changes.
Delete and Undelete Commands
Delete commands are used to delete branches, instructions, and rungs. In
addition, undelete commands are used to copy an instruction or a rung and
create new instructions or rungs.
Deleting a Branch
Use the delete branch command to remove a parallel branch and the
instructions located within the branch. Modify rung 1 of your program to
appear as follows:
] [
I:1.0
0
( )
O:3.0
1
] [
I:1.0
1
( )
O:3.0
2
Important: Unlike the delete rung and delete instruction commands, there is
no associated undelete branch command, in the HHT, to
re–insert a deleted branch.
