Chapter 10
Downloading/Uploading a Program
10–4
In this example you will upload program 03CLOCK stored in processor
node 3. The processor can be in any mode to upload a program.
1. Start at the main menu display:
SLC 500 PROGRAMMING SOFTWARE Rel. 2.03
1747 – PTA1E
Allen–Bradley Company Copyright 1990
All Rights Reserved
F1 F2 F3 F4 F5
PRESS A FUNCTION KEY
SELFTEST
TERM PROGMAINT
OFL
UTILITY
2. Press [F5] , UTILITY. The following display appears if a password is
required:
SLC 500 PROGRAMMING SOFTWARE Rel. 2.03
1747 – PTA1E
Allen–Bradley Company Copyright 1990
All Rights Reserved
F1 F2 F3 F4 F5
ENTER PASSWORD: OFL
or this display appears after the password is entered (for the current
offline program, which is 1000) or if a password is not required:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
ONLINE WHO PASSWRD
OFL
CLR_MEM
3. Press [F2] , WHO, then use the [
↑
] and [
↓
] keys to display node 3 as the
current node. The display should appear as follows:
Node Addr. Device Max Addr./Owner
3 500–20 (5)
4 5/01 (5)
5 5/02 (5)
1 TERMINAL (5)
Node Addr: 3 Baud Rate: 19200
F1 F2 F3 F4 F5
DIAGNSTC
OFL
OWNER
Indicates that node 3
is the current node.
ATTACH NODE_CFG
