Chapter 14
Using EEPROMs and UVPROMs
14–2
5. Press [ ENTER ] to view the remaining menu selections:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
PASSWRD XFERMEM EDT_DAT
PRG
MONITOR>
6. Press [ F3 ], XFERMEM.
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
MEM_PRC PRC_MEM
PRG
Choices are memory to processor (MEM_PRC) and processor to memory
(PRC_MEM).
7. To transfer the processor program to the EEPROM, press [ F4 ],
PRC_MEM.
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
YES NO
PRG XFER PROC TO MEMORY MODULE?
The prompt line asks you to verify your choice.
8. Press [ F2 ]. The prompt line indicates XFERRING PROC TO MEMORY
MODULE momentarily, then returns to this display:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
PASSWRD XFERMEM EDT_DAT
PRG
MONITOR>
A copy of the program has been transferred to the EEPROM.
