Chapter 13
The Force Function
13–3
Function Key
Description
[
F1
], ON
Enters a 1 in the input force table for the cursored external
input bit address. This installs a force. If the Enable
function is in effect and the processor is in the Run or Test
mode, the force is applied. The data file bit remains forced
until: 1) the disable function is in effect, or 2) the force is
removed.
[
F2
], OFF
Enters a 0 in the input force table for the cursored external
input bit address. This installs a force. If the Enable
function is in effect and the processor is in the Run or Test
mode, the force is applied. The data file bit remains forced
until: 1) the disable function is in effect, or 2) the force is
removed.
[
F3
], REM
Affects the cursored external input bit address. If
applicable, removes the installed force from the force table
and the data file. Other forces are unaffected.
[
F4
], REM_ALL
Affects all forced external input bit addresses and external
output circuits. Removes installed forces from all external
input bit addresses and output circuits. You must confirm
your choice.
[
F5
], ENABLE
Toggles between enable and disable all forces, both inputs
and outputs. You must confirm your choice. The disable
function is in effect when no forces are enabled. Note that
the processor must be in the Run or Test mode to see the
effects of the forced input data bits.
2. Force the input on. Press [
F1
], ON.
FORCE ON
is indicated.
ON OFF REM REM_ALL ENABLE
] [
F RUN
F1
F2
F3
F4
F5
XIC: I1:0.0/1 FORCE ON 2.0.0.0.1
( )
( )
]/[
] [
]/[
] [
]/[
( )
( )
] [
] [
] [
The force is installed, but not yet enabled. This is indicated by the
flashing F appearing on the prompt line. This is also indicated by the
FORCED I/O LED on the controller, which is now flashing.
3. Enable the force by pressing [
F5
], ENABLE. The prompt
ARE YOU
SURE?
is indicated.
YES NO
] [
ARE YOU SURE? F RUN
F1
F2
F3
F4
F5
XIC: I1:0.0/1 FORCE ON 2.0.0.0.1
( )
( )
]/[
] [
]/[
] [
]/[
( )
( )
] [
] [
] [
