Chapter 7
Creating and Editing a Program File
7–7
This zoom display, once again gives you a chance to verify that all the
information entered is accurate. Notice that the address displayed is
shown in its full format:
ENTER BIT ADDR: I1:1.0/0
ZOOM on XIC
NAME:
EXAMINE IF CLOSED
BIT ADDR: I1:1.0/0
F1 F2 F3 F4 F5
] [ 2.0.0.0.*
EDT_DAT ACCEPT
6. Press [F5] , ACCEPT. This inserts the instruction and address into the
rung. The following rung display appears:
F1 F2 F3 F4 F5
>
OFL
2.0.0.0.*
] [
< END >
I I
] [ ( ) ]/[ ( ) L ( ) U
Notice that the cursor is now located on the right power rail of rung 0. In
the next section, the Output Energize instruction is inserted to the left of
the cursor.
Further instructions may be entered in the same way.
Entering an Output Energize Instruction
1. Press [F3] , —( )— , for the output energize instruction. The following
display appears:
ENTER BIT ADDR:
ZOOM on OTE
NAME: OUTPUT
ENERGIZE
BIT ADDR:
F1 F2 F3 F4 F5
2.0.0.0.* ( )
2. Type bit address O:3/0 , then press [ENTER] .
ENTER BIT ADDR: O0:3.0/0
ZOOM on OTE
NAME: OUTPUT
ENERGIZE
BIT ADDR: O0:3.0/0
F1 F2 F3 F4 F5
2.0.0.0.* ( )
EDT_DAT ACCEPT
