Page 193

Monitoring Controller Operations

Chapter 12

12–7

The displays below show the 33–word status file for a SLC 5/02 processor.
To move between displays, press [

], NEXT_PG. To display the next

consecutive data file – the bit data file, press [

], NEXT_FL.

Status File
Arithmetic Flags S:0 Z:0 V:0 C:0
S2:0 Proc Status 0000 0000 0000 0000
S2:1 Proc Status 0000 0000 1000 0001
S2:2 Proc Status 1000 0000 0000 0010

S2:0/0 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:5 Minor Fault 0000 0000 0000 0000
S2:6 Fault Code 0000H
Desc: No Error
S2:29 Err File: 0 Indx Cross File: No
S2:24 Index Reg: 0 Single Step: No
S2:5/0 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:7 Suspend Code 0
S2:8 Suspend File 0
S2:4 Running Clock 0000 0000 0000 0000
S2:13&14 Math Register 00000000H

S2:7 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:15H Communication KBaud Rate 19.2
S2:15L Processor Address 1
Note:
Enter 1 for 1200 Enter 3 for 9600
Enter 2 for 2400 Enter 4 for 19200
S2:15H = 4 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:9 & S2:10 Active Node List
1 2 3
0 0 0 0
0111 1000 0000 0000 0000 0000 0000 0000
Node = 0
S2:9/0 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:11 & S2:12 I/O Slot Enables
1 2 3
0 0 0 0
1111 1111 1111 1111 1111 1111 1111 1111
Slot = 0
S2:11/0 = 1 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:3H Watchdog [x10mS] 10

S2:3L Last Scan [x10mS] 0
S2:23 Avg. Scan [x10mS] 0
S2:22 Max. Scan [x10mS] 2
S2:3H = 10 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
Selectable Timed Interrupt
S2:31 Subroutine File: 0
S2:30 Frequency [x10mS]: 0
Enabled: 0 Executing: 0 Pending: 0

S2:31 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
Debug Single Step
File Rung
S2:16&17 Single Step 0 0
S2:18&19 Breakpoint 0 0
S2:20&21 Fault/Powerdown 1 2
S2:16 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:27 & S2:28 I/O Interrupt Enables
1 2 3
0 0 0 0
0000 0000 0000 0000 0000 0000 0000 0000

S2:27/0 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG

Status File
S2:25 & S2:26 I/O Interrupt Pending
1 2 3
0 0 0 0
0000 0000 0000 0000 0000 0000 0000 0000

S2:25/0 = 0 PRG
ADDRESS NEXT FL PREV FL NEXT PG PREV PG
