Chapter 6
Creating a Program
6–7
9. Press
[ESC]
. The following display appears:
–––––– Advanced I/O Configuration ––––––
Current Subroutine File:
0
Current Configuration File:
G6
F1
F2
F3
F4
F5
OFL
INT_SBR MOD_SET
CFG_SIZ ADV_SIZ
10.Set the G file (configuration file) size to 3. Press
[F3]
, CFG_SIZ. The
following display appears:
–––––– Advanced I/O Configuration ––––––
Current Subroutine File:
0
Current Configuration File:
G6
ENTER CONFIG. FILE SIZE: 0
F1
F2
F3
F4
F5
OFL
11. Type
3
, then press
[ENTER]
. You are returned to the previous display.
Press
[F2]
, MOD_SET to view or modify the G file contents. The
following display appears, with the cursor positioned on G6:0:
Address
HEX/BCD
Data
G6:0
2020
G6:1
0000
G6:2
0000
ELEMENT CANNOT BE EDITED!
F1
F2
F3
F4
F5
OFL
BIN
DEC
HEX/BCD NEXT_PG PREV_PG
Indicates Slot 6
Word 0 of the G file is configured automatically by the processor
according to the particular specialty I/O module. Word 0 is read only.
For a description of G files, refer to page 4–27 in this manual.
12.Press
[
↓
]
to edit other words in the G file. The display changes as
follows:
Address
HEX/BCD
Data
G6:1
0000
G6:2
0000
G6:0
2020
G6:1 = 000
F1
F2
F3
F4
F5
OFL
BIN
DEC
HEX/BCD NEXT_PG PREV_PG
