Chapter 9
Configuring Online Communication
9–3
Because the program files match, there are 2 menu screens and 10 function
keys. The greater than sign (
> ), in the lower right corner of the display,
indicates that a second function key menu is available.
The following functions are available to you:
Function Key Description
[ F1 ], OFFLINE Returns you to the utility menu display.
[ F2 ], UPLOAD
Reads the program from the processor RAM and
copies it to the HHT RAM. This function
overwrites any program currently stored in HHT
RAM.
[ F3 ], DOWNLOAD
Copies the program stored in HHT RAM to the
processor RAM. This function overwrites the
program stored in the processor RAM.
[ F4 ], MODE
Allows you to change the processor operating
mode to Run, Test, or Program.
[ F5 ], CLR_PRC
Allows you to the clear the processor RAM and
place the memory in the Default state.
Pressing [ENTER] displays the second set of function keys.
Function Key Description
[ F1 ], PASSWORD
Allows you to change the processor
password/master password.
[ F3 ], TRANSFER MEMORY
Transfers processor RAM to EEPROM or
EEPROM/UVPROM to processor RAM.
[ F4 ], EDT_DAT
Allows you to monitor or edit processor data
files.
[ F5 ], MONITOR
Allows you to observe the program operation of
the processor program file that you specify.
Exceptions
The function keys and menus vary depending on how the HHT and processor
programs relate. In the following example, assume that the HHT has
previously been attached to this processor, but the offline program in the
HHT has been altered and no longer matches the program in processor RAM.
If the HHT and processor programs do not match, the following display
appears when you press
[F1] , ONLINE:
Program Directory
Programmer Processor
F1 F2 F3 F4 F5
CLR_PRC DWNLOAD OFFLINE MODE UPLOAD
Prog: 1000 Prog: 1000
File: 222 File:
Exec Files: 4 Exec Files: 4
Data Files: 9 Data Files: 9
PROGRAM FILES DIFFER RUN
When the program files do not match, there is only one menu display and
five function keys. Notice the absence of the greater than sign (
> ), in the
lower right corner.
