15 Parameter reference
15.2 Parameter list | C00838
998
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00838
Parameter | Name:
C00838 | Binary inputs (Set2)
Data type: UNSIGNED_8
Index: 23737
d
= 5CB9
h
Display of the signal status of the binary inputs of different blocks
• In addition to the parameter C00833 .
• Non-listed subcodes are "reserved".
Selection list
0 False
1 True
Subcodes Info
C00838/1 L_And5_1 : bIn1
C00838/2 L_And5_1 : bIn2
C00838/3 L_And5_1 : bIn3
C00838/4 L_And5_1 : bIn4
C00838/5 L_And5_1 : bIn5
C00838/6 L_And5_2 : bIn1
C00838/7 L_And5_2 : bIn2
C00838/8 L_And5_2 : bIn3
C00838/9 L_And5_2 : bIn4
C00838/10 L_And5_2 : bIn5
C00838/11 L_AnalogSwitch_4 : bSet
C00838/12 L_AnalogSwitch_5 : bSet
C00838/13 L_DFlipFlop_2 : bD
C00838/14 L_DFlipFlop_2 : bClk
C00838/15 L_DFlipFlop_2 : bClr
C00838/16 L_DigitalDelay_2 : bIn
C00838/17 L_DigitalDelay_3 : bIn
C00838/18 L_PhaseIntK_1 : bLoad
C00838/19 L_PhaseIntK_2 : bLoad
C00838/20 L_DigitalLogic_2 : bIn1
C00838/21 L_DigitalLogic_2 : bIn2
C00838/22 L_DigitalLogic_2 : bIn3
C00838/23 L_DigitalLogic5_1 : bIn1
C00838/24 L_DigitalLogic5_1 : bIn2
C00838/25 L_DigitalLogic5_1 : bIn3
C00838/26 L_DigitalLogic5_1 : bIn4
C00838/27 L_DigitalLogic5_1 : bIn5
C00838/28 L_DigitalLogic5_2 : bIn1
C00838/29 L_DigitalLogic5_2 : bIn2
C00838/30 L_DigitalLogic5_2 : bIn3
C00838/31 L_DigitalLogic5_2 : bIn4
C00838/32 L_DigitalLogic5_2 : bIn5
C00838/33 L_NLim_2 : bEnable
C00838/34 L_Or5_1 : bIn1
C00838/35 L_Or5_1 : bIn2
C00838/36 L_Or5_1 : bIn3
