Lenze 8400 HighLine - Manual (Page 930)

15 Parameter reference
15.2 Parameter list | C00621
930
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00621
C00620/71 0: Not connected LS_ParReadWrite_6 : wInHWord
Read/write request 6: Value (high word)
C00620/72 0: Not connected LS_ParReadWrite_6 : wInLWord
Read/write request 6: Value (low word)
C00620/89 0: Not connected LS_RetainData : wIn1
Retain data: 16-bit input value 1
C00620/90 0: Not connected LS_RetainData : wIn2
Retain data: 16-bit input value 2
C00620/91 0: Not connected LS_RetainData : wIn3
Retain data: 16-bit input value 3
C00620/92 0: Not connected LS_RetainData : wIn4
Retain data: 16-bit input value 4
C00620/108 0: Not connected LP_CanOut4 : wOut1
CAN4 output: Data word 1
C00620/109 0: Not connected LP_CanOut4 : wOut2
CAN4 output: Data word 2
C00620/110 0: Not connected LP_CanOut4 : wOut3
CAN4 output: Data word 3
C00620/111 0: Not connected LP_CanOut4 : wOut4
CAN4 output: Data word 4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00620 | System connection list: 16-bit
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
Parameter | Name:
C00621 | System connection list: Bool
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
Connection parameters: Binary inputs
• Selection of the binary output signals to be connected to the binary input signals
• The selection list contains all binary output signals which can be assigned to the binary inputs mapped by the
subcodes.
• Non-listed subcodes are "reserved".
Selection list
See
selection list - digital signals
Subcodes Lenze setting Info
C00621/1 1001: LA_NCtrl: bDriveFail LS_DigitalOutput : bRelay
Digital relay output: Input signal
C00621/2 1000: LA_NCtrl: bDriveReady LS_DigitalOutput : bOut1
Digital output 1: Input signal
C00621/3 0: Not connected LS_DigitalInput : bCountIn1_Reset
Digital input 1: Reset counter
C00621/4 0: Not connected LS_DigitalInput : bCountIn1_LoadStartValue
Digital input 1: Load counter starting value
C00621/5 0: Not connected LP_CanOut1 : bState_B0
CAN1 output: Status word - bit 0
C00621/6 0: Not connected LP_CanOut1 : bState_B1
CAN1 output: Status word - bit 1
C00621/7 0: Not connected LP_CanOut1 : bState_B2
CAN1 output: Status word - bit 2
C00621/8 0: Not connected LP_CanOut1 : bState_B3
CAN1 output: Status word - bit 3
