15 Parameter reference
15.2 Parameter list | C00622
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00622
C00621/188 0: Not connected LP_CanOut4 : bOut1_B4
CAN4 output: Data word 1- bit 4
C00621/189 0: Not connected LP_CanOut4 : bOut1_B5
CAN4 output: Data word 1- bit 5
C00621/190 0: Not connected LP_CanOut4 : bOut1_B6
CAN4 output: Data word 1- bit 6
C00621/191 0: Not connected LP_CanOut4 : bOut1_B7
CAN4 output: Data word 1- bit 7
C00621/192 0: Not connected LP_CanOut4 : bOut1_B8
CAN4 output: Data word 1- bit 8
C00621/193 0: Not connected LP_CanOut4 : bOut1_B9
CAN4 output: Data word 1- bit 9
C00621/194 0: Not connected LP_CanOut4 : bOut1_B10
CAN4 output: Data word 1- bit 10
C00621/195 0: Not connected LP_CanOut4 : bOut1_B11
CAN4 output: Data word 1- bit 11
C00621/196 0: Not connected LP_CanOut4 : bOut1_B12
CAN4 output: Data word 1- bit 12
C00621/197 0: Not connected LP_CanOut4 : bOut1_B13
CAN4 output: Data word 1- bit 13
C00621/198 0: Not connected LP_CanOut4 : bOut1_B14
CAN4 output: Data word 1- bit 14
C00621/199 0: Not connected LP_CanOut4 : bOut1_B15
CAN4 output: Data word 1- bit 15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00621 | System connection list: Bool
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
Parameter | Name:
C00622 | System connection list: Angle
Data type: UNSIGNED_16
Index: 23953
d
= 5D91
h
Connection parameters: 32-bit inputs
• Selection of the 32-bit output signals for connection with the 32-bit input signals.
• The selection list contains all 32-bit output signals which can be assigned to the 32-bit inputs mapped by the
subcodes.
• Non-listed subcodes are "reserved".
Selection list
See
selection list - angle signals
Subcodes Lenze setting Info
C00622/1 0: Not connected LS_DisFree_p : dnDis1_p
Display of 32-bit signal 1
C00622/2 0: Not connected LS_DisFree_p : dnDis2_p
Display of 32-bit signal 2
C00622/3 0: Not connected LS_DisFree_p : dnDis3_p
Display of 32-bit signal 3
C00622/4 0: Not connected LS_DisFree_p : dnDis4_p
Display of 32-bit signal 4
C00622/5 0: Not connected LS_DisFree_p : dnDis5_p
Display of 32-bit signal 5
C00622/6 0: Not connected LS_DisFree_p : dnDis6_p
Display of 32-bit signal 6
