15 Parameter reference
15.2 Parameter list | C01108
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01108
C01120
C01121
Parameter | Name:
C01108 | L_SwitchPoint_1: Dead time factor
Data type: UNSIGNED_8
Index: 23467
d
= 5BAB
h
From version 14.00.00
Selection list
1 1 μs
2 10 μs
3 100 μs
4 1000 μs
Subcodes Lenze setting Info
C01108/1 2: 10 μs L_SwitchPoint_1 : Deadtime factor 1
C01108/2 2: 10 μs L_SwitchPoint_1 : Deadtime factor 2
C01108/3 2: 10 μs L_SwitchPoint_1 : Deadtime factor 3
C01108/4 2: 10 μs L_SwitchPoint_1 : Deadtime factor 4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01120 | Sync signal source
Data type: UNSIGNED_8
Index: 23455
d
= 5B9F
h
From version 02.00.00
Selection of the signal source for device synchronisation
• The drive can only be synchronised by one source.
 Synchronisation of the internal time base
Selection list (Lenze setting printed in bold) Info
0 Off Synchronisation off
1 CAN on board Synchronisation via CAN bus

Sync telegram
4 MCI Synchronisation via MCI (communication module)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01121 | Sync cycle time setpoint
Data type: UNSIGNED_16
Index: 23454
d
= 5B9E
h
From version 04.00.00
Cycle time setpoint for device synchronisation
• Time interval at which the phase control loop (PLL) in the controller expects the synchronisation signals.
• The cycle time setpoint must be set according to the cycle of the respective synchronisation source.
Note:
• Only integer multiples of 1000 μs can be set.
• Intelligent communication modules usually define the cycle time setpoint derived from the bus cycle. In this
case, a manual change is not possible.
Example: For the CAN bus, a distance of 2 ms has been set between two synchronisation signals. If the CAN bus is
to be used as synchronisation source, a synchronisation cycle of 2000 μs must be set in C01121.
 Synchronisation of the internal time base
Setting range (min. value | unit | max. value) Lenze setting
1000 μs 20000 1000 μs
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
