15 Parameter reference
15.2 Parameter list | C00959
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00959
C00960
C00961
Parameter | Name:
C00959 | L_Curve: Current output value
Data type: INTEGER_16
Index: 23616
d
= 5C40
h
From version 11.00.00
FB L_Curve_1 : Display of the current output value nOut_a
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00959/1 L_Curve_1 : Current output value
C00959/2 L_Curve_2 : Current output value
C00959/3 L_Curve_3 : Current output value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00960 | L_Curve_1: Selected curve type
Data type: UNSIGNED_8
Index: 23615
d
= 5C3F
h
From version 04.00.00
FB L_Curve_1 : Selected curve type
Selection list
0 Out = 0
1 Out = In
2 Out = f(In)
3 Out = f(table)
Subcodes Lenze setting Info
C00960/1 1: Out = In L_Curve_1 : Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00961 | L_Curve_1: Input limitation
Data type: INTEGER_16
Index: 23614
d
= 5C3E
h
From version 04.00.00
FB L_Curve_1 : Upper and lower limit for input value
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00961/1 199.99 % L_Curve_1 : Max. input
C00961/2 -199.99 % L_Curve_1 : Min. input
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
