15 Parameter reference
15.2 Parameter list | C00621
936
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00621/152 0: Not connected LS_TouchProbe : bDisableTPDigIn3_Rising
TP input DI3: Disable recognition of rising edges
dynamically
C00621/153 0: Not connected LS_TouchProbe : bDisableTPDigIn3_Falling
TP input DI3: Disable recognition of falling edges
dynamically
C00621/154 0: Not connected LS_TouchProbe : bDisableTPDigIn4_Rising
TP input DI4: Disable recognition of rising edges
dynamically
C00621/155 0: Not connected LS_TouchProbe : bDisableTPDigIn4_Falling
TP input DI4: Disable recognition of falling edges
dynamically
C00621/156 0: Not connected LS_TouchProbe : bDisableTPDigIn5_Rising
TP input DI5: Disable recognition of rising edges
dynamically
C00621/157 0: Not connected LS_TouchProbe : bDisableTPDigIn5_Falling
TP input DI5: Disable recognition of falling edges
dynamically
C00621/158 0: Not connected LS_TouchProbe : bDisableTPDigIn3Window
TP input DI3: Enable acceptance window
C00621/159 0: Not connected LS_TouchProbe : bDisableTPDigIn4Window
TP input DI4: Enable acceptance window
C00621/160 0: Not connected LS_TouchProbe : bDisableTPDigIn5Window
TP input DI5: Enable acceptance window
C00621/164 0: Not connected Reserved
C00621/165 0: Not connected LS_RetainData : bSetRetain_1
Retain data: Save input values (selection 1) in retain
memory
C00621/166 0: Not connected LS_RetainData : bSetRetain_2
Retain data: Save input values (selection 2) in retain
memory
C00621/167 0: Not connected LS_RetainData : bSetRetain_3
Retain data: Save input values (selection 3) in retain
memory
C00621/168 0: Not connected LS_RetainData : bLoadParams
Retain data: Set selected outputs & retain values to
parameter values
C00621/169 0: Not connected LS_RetainData : bIn1
Retain data: Binary input value 1
C00621/170 0: Not connected LS_RetainData : bIn2
Retain data: Binary input value 2
C00621/171 0: Not connected LS_RetainData : bIn3
Retain data: Binary input value 3
C00621/172 0: Not connected LS_RetainData : bIn4
Retain data: Binary input value 4
C00621/184 0: Not connected LP_CanOut4 : bOut1_B0
CAN4 output: Data word 1- bit 0
C00621/185 0: Not connected LP_CanOut4 : bOut1_B1
CAN4 output: Data word 1- bit 1
C00621/186 0: Not connected LP_CanOut4 : bOut1_B2
CAN4 output: Data word 1- bit 2
C00621/187 0: Not connected LP_CanOut4 : bOut1_B3
CAN4 output: Data word 1- bit 3
Parameter | Name:
C00621 | System connection list: Bool
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
