Lenze 8400 HighLine - Manual (Page 1036)

15 Parameter reference
15.2 Parameter list | C01028
1036
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01028
C01029
C01030
Parameter | Name:
C01028 | L_Curve_2: Table X-values
Data type: INTEGER_16
Index: 23547
d
= 5BFB
h
From version 11.00.00
FB L_Curve_2 : X-values for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01028/1 0 X values 1 ... 32 for characteristic function
C01028/...
C01028/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01029 | L_Curve_2: Table Y-values
Data type: INTEGER_16
Index: 23546
d
= 5BFA
h
From version 11.00.00
FB L_Curve_2 : Y-value for characteristic function
Setting range
(min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01029/1 0 Y values 1 ... 32 for characteristic function
C01029/...
C01029/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01030 | L_Curve_3: Selected curve type
Data type: UNSIGNED_8
Index: 23545
d
= 5BF9
h
From version 11.00.00
FB L_Curve_3 : Selected curve type
Selection list Info
0 Out = 0
1 Out = In
2 Out = f(In)
3 Out = f(table)
4 Out = f(characteristic)
From version 12.00.00
Subcodes Lenze setting Info
C01030/1 1: Out = In L_Curve_3 : Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
