Lenze 8400 HighLine - Manual (Page 1020)

15 Parameter reference
15.2 Parameter list | C00919
1020
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00919
C00922
C00937
C00938
C00939
Parameter | Name:
C00919 | Moment of inertia from load
Data type: UNSIGNED_32
Index: 23656
d
= 5C68
h
From version 12.00.00
In order to take account of mass inertias changing during the process (e.g. reels) when optimising the response to
setpoint changes, the maximum value of the changing moment of inertia must be set here. The process signal
nInertiaAdapt_a of the LS_MotorInterface SB can then be used in the process to dynamically control what
percentage of it is to be taken into account for the setpoint feedforward control.
Setting range
(min. value | unit | max. value)
0.00 kg cm^2 6000000.00
Subcodes Lenze setting Info
C00919/1 0.00 kg cm^2 Load moment of inertia
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00922 | ICM_DiagnosticCounter
Data type: UNSIGNED_16
Index: 23653
d
= 5C65
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00937 | Field-oriented motor currents
Data type: INTEGER_16
Index: 23638
d
= 5C56
h
From version 11.00.00
 Field weakening for synchronous motors
Display range (min. value | unit | max. value)
-320.00 A 320.00
Subcodes Info
C00937/1 Field-producing current
C00937/2 Torque-producing current
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00938 | PSM: Maximum motor current field weakening
Data type: UNSIGNED_16
Index: 23637
d
= 5C55
h
From version 11.00.00
 Field weakening for synchronous motors
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 500.00 30.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00939 | Ultimate motor current
Data type: UNSIGNED_16
Index: 23636
d
= 5C54
h
From version 10.00.00
Setting range (min. value | unit | max. value) Lenze setting
0.0 A 3000.0 3000.0 A
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
