15 Parameter reference
15.2 Parameter list | C00643
942
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00643
C00650
Parameter | Name:
C00643 | Resp. to PLI monitoring
Data type: UNSIGNED_8
Index: 23932
d
= 5D7C
h
From version 11.00.00
 Pole position identification without motion
Selection list
0 No Reaction
1 Fault
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C00643/1 1: Fault Response to PLI monitoring
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00650 | L_Arithmetik 3-5: Function
Data type: UNSIGNED_8
Index: 23925
d
= 5D75
h
Selection of the internal arithmetics
Selection list
0 nOut_a = nIn1_a
1 nOut_a = nIn1_a + nIn2_a
2 nOut_a = nIn1_a - nIn2_a
3 nOut_a = (nIn1_a * nIn2_a) / 100%
4 nOut_a = (nIn1_a * 1%) / |nIn2_a|
5 nOut_a = (nIn1_a * 100%) / (100% -
nIn2_a)
Subcodes Lenze setting Info
C00650/1 0: nOut_a = nIn1_a L_Arithmetik_3 : Function
C00650/2 0: nOut_a = nIn1_a L_Arithmetik_4 : Function
C00650/3 0: nOut_a = nIn1_a L_Arithmetik_5 : Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
