3 Commissioning
3.8 Commissioning of the "Table positioning" technology application
68
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.8.2 Creating an »Engineer« project & going online
The following steps serve to describe a general method for creating a project with the Select
component from catalogue option. For this purpose, individual components (controller, motor, etc.)
are selected from selection lists.
1. Start the »Engineer«.
2. Create a new project with the Start-up wizard and the Select component from catalogue option:
• In the Component step, select the 8400 HighLine controller.
• In the Device modules step, select the available communication module.
• In the Application step, select the "Table positioning" application. (The application can also
be selected any time afterwards via the Application parameter tab or C00005 .)
• Select the other components (motor/gearbox) to be added to the project in the Other
components dialog step.
3. Go online.
After a connection to the controller has been established, the following status is displayed in the
Status line:
4. Transfer parameter set to the device.
This command serves to overwrite the current parameter settings in the controller by
parameter settings of the »Engineer« project.

You can find detailed information on the general use of the »Engineer« in the online help
which you can call with [F1].
• The chapter "Working with projects" describes, among other things, all options of the
Start-up wizard which are available to create a new »Engineer« project.
