15 Parameter reference
15.2 Parameter list | C01093
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01093
C01094
Parameter | Name:
C01093 - LS_ParReadWrite 1-6: Arithmetic mode
Data type: UNSIGNED_8
Index: 23482
d
= 5BBA
h
From version 06.00.00
The integrated arithmetic function allows for easy arithmetic conversion of the process value to be written or which
was read into the format of the target parameter via parameterisable factors and without the need for an
additional arithmetic FB.
Selection list
0 No arithmetic
1 In16Bit: LW=+/-32767
2 In16Bit: HW=+/-; LW=0..65535
3 In32Bit: HW_LW=+/-2147483647
Subcodes Lenze setting Info
C01093/1 0: no arithmetic LS_ParReadWrite_1 : Arithmetic mode
C01093/2 0: no arithmetic LS_ParReadWrite_2 : Arithmetic mode
C01093/3 0: no arithmetic LS_ParReadWrite_3 : Arithmetic mode
C01093/4 0: no arithmetic LS_ParReadWrite_4 : Arithmetic mode
C01093/5 0: no arithmetic LS_ParReadWrite_5 : Arithmetic mode
C01093/6 0: no arithmetic LS_ParReadWrite_6 : Arithmetic mode
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01094 - LS_ParReadWrite 1-6: Numerator
Data type: INTEGER_16
Index: 23481
d
= 5BB9
h
From version 06.00.00
Arithmetic function : Factor (numerator) for internal conversion in arithmetic modes 1 ... 3.
Setting range
(min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01094/1 1 LS_ParReadWrite_1 : Numerator
C01094/2 1 LS_ParReadWrite_2 : Numerator
C01094/3 1 LS_ParReadWrite_3 : Numerator
C01094/4 1 LS_ParReadWrite_4 : Numerator
C01094/5 1 LS_ParReadWrite_5 : Numerator
C01094/6 1 LS_ParReadWrite_6 : Numerator
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
