15 Parameter reference
15.2 Parameter list | C00072
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00072
C00073
C00074
C00075
Parameter | Name:
C00072 | SC: Tdn speed controller
Data type: UNSIGNED_16
Index: 24503
d
= 5FB7
h
Differential time constant Tdn of the speed controller for servo control ( SC ) and sensorless control for synchronous
motors ( SLPSM )
Setting range (min. value | unit | max. value) Lenze setting
0.00 ms 3.00 0.00 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00073 | Imax/M controller gain
Data type: UNSIGNED_16
Index: 24502
d
= 5FB6
h
Amplification factor Vp of certain controllers for different motor control modes
Setting range
(min. value | unit | max. value)
0.00 100.00
Subcodes Lenze setting Info
C00073/1 0.25 VFC : Vp Imax controller
• After the motor to be used has been selected from the
motor catalogue, the suitable value can be entered
automatically.
C00073/2 1.25 SLVC : Vp torque controller
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00074 | Reset time Imax/M controller
Data type: UNSIGNED_16
Index: 24501
d
= 5FB5
h
Reset time Ti of certain controllers for different motor control modes
Setting range
(min. value | unit | max. value)
0 ms 9990
Subcodes Lenze setting Info
C00074/1 65 ms VFC : Ti Imax controller
C00074/2 30 ms SLVC : Ti torque controller
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00075 | Vp current controller
Data type: UNSIGNED_16
Index: 24500
d
= 5FB4
h
Gain factor Vp of the current controller for servo control ( SC ) and certain inverter functions (parameter
identification, flying restart circuit)
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered
automatically.
Setting range
(min. value | unit | max. value)
Lenze setting
0.00 V/A 500.00 7.00 V/A
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
