15 Parameter reference
15.2 Parameter list | C00963
1024
Lenze · 8400 HighLine · Referenzhandbuch · DMS 10.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00963
C00964
C00965
C00966
Parameter | Name:
C00963 | L_Curve_1: Table X-values
Data type: INTEGER_16
Index: 23612
d
= 5C3C
h
From version 04.00.00
FB L_Curve_1 : X-values for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C00963/1 0 X values 1 ... 32 for characteristic function
C00963/...
C00963/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00964 | L_Curve_1: Table Y-values
Data type: INTEGER_16
Index: 23611
d
= 5C3B
h
From version 04.00.00
FB L_Curve_1 : Y-value for characteristic function
Setting range
(min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C00964/1 0 Y values 1 ... 32 for characteristic function
C00964/...
C00964/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00965 | Max. motor speed
Data type: UNSIGNED_16
Index: 23610
d
= 5C3A
h
From version 10.00.00
When the drive reaches the motor speed set here:
• The "Fault" error response takes place, i.e. the motor is shut down immediately.
• The error message " oS2: Max. motor speed reached " is entered into the logbook.
Setting range (min. value | unit | max. value) Lenze setting
50 rpm 65000 60000 rpm
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00966 | VFC: Time const. slip comp.
Data type: UNSIGNED_16
Index: 23609
d
= 5C39
h
Filter time constant of the slip compensation for V/f characteristic control ( VFCplus )
• The time constant of slip compensation serves to specify the dynamics of slip compensation for V/f characteristic
control without feedback.
• The lower the selected time constant, the higher the dynamic performance of the slip compensation.
Setting range (min. value | unit | max. value) Lenze setting
1 ms 6000 100 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
