15 Parameter reference
15.6 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01074 L_DFSET_1: Zero pulse divider Linear value 23501 5BCD A 2 UNSIGNED_16 1
C01075 L_DFSET_1: Synchronisation mode Selection list 23500 5BCC A 1 UNSIGNED_8 1
C01076 L_DFRFG_1: Times Linear value 23499 5BCB A 2 UNSIGNED_32 1000
C01077 L_DFRFG_1: Max. speed-up Linear value 23498 5BCA A 1 INTEGER_16 1
C01078 L_DFRFG_1: Following error Linear value 23497 5BC9 A 1 UNSIGNED_32 1
C01079 L_DFRFG_1: Synchronisation window Linear value 23496 5BC8 A 1 UNSIGNED_16 1
C01080 L_DFRFG_1: Offset Linear value 23495 5BC7 A 1 INTEGER_32 1
C01081 L_DFRFG_1: Sync. direction / TP function Selection list 23494 5BC6 A 1 UNSIGNED_8 1
C01082 LS_WriteParamList: Execute Mode Selection list 23493 5BC5 E 1 UNSIGNED_8 1
C01083 LS_WriteParamList: Error status Linear value 23492 5BC4 E 1 UNSIGNED_16 1
C01084 LS_WriteParamList: Error line Linear value 23491 5BC3 E 1 UNSIGNED_8 1
C01085 LS_WriteParamList: Index Linear value 23490 5BC2 A 32 INTEGER_32 1000
C01086 LS_WriteParamList: WriteValue_1 Linear value 23489 5BC1 A 32 INTEGER_32 1
C01087 LS_WriteParamList: WriteValue_2 Linear value 23488 5BC0 A 32 INTEGER_32 1
C01088 LS_WriteParamList: WriteValue_3 Linear value 23487 5BBF A 32 INTEGER_32 1
C01089 LS_WriteParamList: WriteValue_4 Linear value 23486 5BBE A 32 INTEGER_32 1
C01090 LS_ParReadWrite 1-6: Index Linear value 23485 5BBD A 6 INTEGER_32 1000
C01091 LS_ParReadWrite 1-6: Cycle time Selection list 23484 5BBC A 6 UNSIGNED_16 1
C01092 LS_ParReadWrite 1-6: FailState Linear value 23483 5BBB A 6 UNSIGNED_16 1
C01093 LS_ParReadWrite 1-6: Arithmetic mode Selection list 23482 5BBA A 6 UNSIGNED_8 1
C01094 LS_ParReadWrite 1-6: Numerator Linear value 23481 5BB9 A 6 INTEGER_16 1
C01095 LS_ParReadWrite 1-6: Denominator Linear value 23480 5BB8 A 6 INTEGER_16 1
C01100 Function L_Counter 1-3 Selection list 23475 5BB3 A 3 UNSIGNED_8 1
C01101 Comparison L_Counter 1-3 Selection list 23474 5BB2 A 3 UNSIGNED_8 1
C01108 L_SwitchPoint_1: Deadtime factor Selection list 23467 5BAB A 4 UNSIGNED_8 1
C01120 Sync signal source Selection list 23455 5B9F E 1 UNSIGNED_8 1
C01121 Sync cycle time setpoint Linear value 23454 5B9E E 1 UNSIGNED_16 1
C01122 Sync phase position Linear value 23453 5B9D E 1 UNSIGNED_16 1
C01123 Sync window Linear value 23452 5B9C E 1 UNSIGNED_16 1
C01124 Sync correction width Selection list 23451 5B9B E 1 UNSIGNED_8 1
C01130 LS_RetainData: Selection Bit coded 23445 5B95 A 4 UNSIGNED_16 1
C01131 LS_RetainData: 16Bit data Linear value 23444 5B94 A 4 UNSIGNED_16 1
C01132 LS_RetainData: 32Bit data Linear value 23443 5B93 A 4 INTEGER_32 1
C01133 LS_RetainData: Bool data Selection list 23442 5B92 A 4 UNSIGNED_8 1
C01138 L_Transient 1-4: Function Selection list 23437 5B8D A 4 UNSIGNED_8 1
C01139 L_Transient 1-4: Pulse duration Linear value 23436 5B8C A 4 UNSIGNED_16 1000
C01140 L_Transient 5-8: Function Selection list 23435 5B8B A 4 UNSIGNED_8 1
C01141 L_Transient 5-8 pulse duration Linear value 23434 5B8A A 4 UNSIGNED_16 1000
C01150 L_PhaseIntK: Function Selection list 23425 5B81 A 2 UNSIGNED_8 1
C01151 L_PhaseIntK: Compare Linear value 23424 5B80 A 2 INTEGER_32 1
C01201 MCK: Cycle Linear value 23374 5B4E A 1 INTEGER_32 10000
C01202 MCK: iM motor/process Linear value 23373 5B4D A 2 UNSIGNED_16 1
C01203 MCK: iG motor/position encoder Linear value 23372 5B4C A 2 UNSIGNED_16 1
C01204 MCK: Feed constant Linear value 23371 5B4B E 1 INTEGER_32 10000
C01205 MCK: Position resolution Linear value 23370 5B4A E 1 INTEGER_32 10000
C01206 MCK: Mounting direction Selection list 23369 5B49 A 2 UNSIGNED_8 1 CINH
C01210 MCK: Current positions Linear value 23365 5B45 A 9 INTEGER_32 10000
C01211 MCK: Speed Linear value 23364 5B44 A 3 INTEGER_32 10000
C01213 MCK: Max. traversing distance Linear value 23362 5B42 A 1 INTEGER_32 1
C01215 MCK: Following error Linear value 23360 5B40 A 3 INTEGER_32 10000
Code Name Type Index Data
dec hex DS DA DT Factor CINH
Grayed out = display parameter (read access only)
