15 Parameter reference
15.2 Parameter list | C02865
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Bit 3 DCB: Current controller and C036
app. to C088
Bit 4 Motorident.: No calculation C73 C75
C76 C77 C78
From version 12.00.00 onwards : Following successful
motor parameter identification, the current controller
and field controller parameters are calculated as well.
If these parameters are not to be calculated, bit 4 must
be set to "1".
0 ≡ Calculate parameter
1 ≡ Do not calculate parameter

Automatic motor data identification
Bit 5 Motorident.: Calculation C70 C71
C72
From version 12.00.00 onwards : Following successful
motor parameter identification, the speed controller
parameters can automatically be calculated as well.
If these parameters are to be calculated, bit 5 must be set
to "1".
0 ≡ Do not calculate parameter
1 ≡ Calculate parameter

Automatic motor data identification
Bit 6 Motorident.: Calculation C11 C22
C497 C966 C982
From version 12.00.00 onwards : Following successful
motor parameter identification, further controller
parameters can be calculated automatically.
If these parameters are to be calculated, bit 6 must be set
to "1".
0 ≡ Do not calculate parameter
1 ≡ Calculate parameter

Automatic motor data identification
Bit 7 Brake chopper off in case of pulse
inhibit
From version 14.00.00
0 ≡ No response of the brake chopper in case of pulse
inhibit.
1 ≡ In case of pulse inhibit, the brake chopper is
permanently switched off without any delay.

Braking operation/brake energy management
Bit 8 DC-bus supply with DC charging
connection
Bit 9 Inverter characteristics inactive From version 12.00.00
In case of very low-inductance motors (e.g. synchronous
motor with a rated frequency of 1000 Hz) the inverter
error characteristic needs to be switched off as otherwise
the current of the device might be switched off.
0 ≡ Inverter error characteristic is active
1 ≡ Inverter error characteristic is not active
Bit 10 SCPSM: Extrapolation - actual speed
value inactive
Bit 11 TopLine: Speed encoder signal cycle
500us
Bit 12 In case of QSP - nTorqueSetValue_a
active
From version 13.00.00
Bit 13 In case of QSP - nTorquexxxLimit_a
active
From version 13.00.00
Bit 14 Sensitivity of setpoint feedf. ctrl. 16
bits
From version 14.00.00
Bit 15 SC: Dead time of speed setpoint
500us
From version 14.00.00
Subcodes Lenze setting Info
C02865/1 0x0000 MCTRL : Special settings
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C02865 | MCTRL: Special settings
Data type: UNSIGNED_16
Index: 21710
d
= 54CE
h
