15 Parameter reference
15.2 Parameter list | C02652
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02652
C02810
Parameter | Name:
C02652 | Settings of measuring system
Data type: UNSIGNED_16
Index: 21923
d
= 55A3
h
From version 11.00.00
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
Value is bit-coded: ( = bit set) Info
Bit 0  Actual MCTRL position received at
mains switch-off
 Actual "MCTRL position received at mains switch-off"
Bit 1  Delete reference when machine data
is changed
From version 12.00.00
 Status bit "HomPosAvailable"
Bit 2  Reserved
Bit 3  Reserved
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C02810 | TP: Edge selection
Data type: UNSIGNED_8
Index: 21765
d
= 5505
h
From version 06.00.00
 Touch-probe detection
Selection list
0 Off
1 Rising
2 Falling
3 Rising and falling
Subcodes Lenze setting Info
C02810/1 0: Off Reserved
C02810/2 0: Off Reserved
C02810/3 0: Off TPDigIn3: Edge selection
C02810/4 0: Off TPDigIn4: Edge selection
C02810/5 0: Off TPDigIn5: Edge selection
C02810/6 0: Off TPDigIn6: Edge selection
C02810/7 0: Off TPDigIn7: Edge selection
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
