3.1
Machine Configuration
3
bizhub PRESS C8000/e
3-24
7CAUTION
DO NOT insert your fingers into the two ADF hinge portions.
-
Otherwise, you may be injured. Please be careful when opening or closing the ADF.
No.
Name
Description
1
Left original conveyance cover
Opens leftward to allow removal of mishandled origi-
nal.
2
ADF original scale
Indicates available original sizes, face to be placed,
and unsuitable originals.
3
Original guides
Aligned to the edges of loaded originals.
4
Original feed tray
Loaded with the original to be scanned. Up to 100
sheets can be set. Opens upward to allow removal of
mishandled original.
5
Original catch tray
Holds the scanned original. Opens upward to allow
removal of mishandled original.
6
Conveyance knob
Turned clockwise to feed mishandled original.
7
Right original conveyance cover
Opens rightward to allow removal of mishandled orig-
inal.
8
Reversed original catch tray
Allows removal of mishandled original.
9
ADF guide cover
Automatically positions the original on the original
glass. Or, closed to cover the original positioned
manually on the original glass.
10
Horizontal size guide
Measures the original size in horizontal direction.
11
Original glass
Scans original images into memory.
12
Vertical size guide
Measures the original size in vertical direction.
