9.5 [03 Finisher Adjustment] (Folding Unit FD-503) 9
bizhub PRESS C8000/e 9-38
8
If any adjustment is required, press [Exit Print Mode] to return to the Gate Position Adjustment Screen.
9
Select [Single Fold].
10
Use the touch panel keypad or control panel keypad to enter the setting data.
% Use [+/-] to specify the value to be positive or negative.
% Press [Set] to change the current data.
% Adjustable range: Single Fold/Triple Fold: -50 (Long) to +50 (Short) (1 step = 0.1 mm) Double Fold:
-50 (Short) to +50 (Long) (1 step = 0.1 mm)
% The measurement (a) in step 7 will increase with positive value entered, and decrease with negative
value entered.
11
Press [Double Fold] or [Triple Fold] similarly to make an adjustment as needed.
% In Double Fold, the measurement (b) in step 7 will increase with positive value entered, and decrease
with negative value entered.
% In Triple Fold, the measurement (c) in step 7 will increase with positive value entered, and decrease
with negative value entered.
12
Repeat the steps from 4 to 11 until the desired result is obtained.
13
Press [Return] to restore the Multi Folder (Fold) Adjustment Menu Screen.
[1] Single Fold [2] Double Fold [3] Triple Fold
