14.4 Output Option Specifications 14
bizhub PRESS C8000/e 14-14
14.4.6 Saddle Stitcher SD-506
Name SD-506
Type Multi folding, folding and stapling, trimming, straight delivery
Delivery modes Secondary (sub) tray
delivery Deliver non-processed sheets to the secondary (sub) tray.
Connective delivery Deliver non-processed sheets to another finishing equip-
ment.
Fold & Staple Output saddle-stitched sets.
Fold & Staple with
Trimming Output saddle-stitched and trimmed sets.
Multi Half Fold Output a sheet or set of paper folded in half.
Multi Half Fold with
Trimming Output a sheet or set of paper half-folded and trimmed in the
edge.
Multi Tri-Fold Output a sheet or set of paper folded in three.
Multi folding Folding type Half fold, tri-fold
Paper size Multi Half Fold: SRA3 w, A3 w, B4 w, SRA4 w, A4 w,
B5 w, Foolscap, 12 e 18 w, 11 e 17 w, 8.5 e 14 w,
8.5 e 11 w
Custom: max. 324 mm e 463 mm to min. 182 mm e 257 mm
Multi Tri-Fold: A4 w, 8.5 e 11 w
Paper weight 64 to 244 g/m
2
for half fold, 64 to 91 g/m
2
for tri-fold
Number of sheets per
folded set 5 sheets (64 to 81 g/m
2
) in half fold/tri-fold
3 sheets (82 to 91 g/m
2
) in tri-fold
3 sheets (82 to 130 g/m
2
), 2 sheets (131 to 244 g/m
2
) in half
fold
Stack capacity 30 sets for half fold
20 sets for tri-fold
Provided with full-load detection function
Folding and sta-
pling Paper size Standard: SRA3 w, A3 w, B4 w, SRA4 w, A4 w, B5 w,
Foolscap, 12 e 18 w, 11 e 17 w, 8.5 e 14 w, 8.5 e 11 w
Custom: max. 324 mm e 463 mm to min. 182 mm e 257 mm
Paper weight 64 to 244 g/m
2
Binding pitch Variable (90 to 165 mm)
Trimming Paper size Standard: SRA3 w, A3 w, B4 w, SRA4 w, A4 w, B5 w,
Foolscap, 12 e 18 w, 11 e 17 w, 8.5 e 14 w, 8.5 e 11 w
Custom: max. 324 mm e 463 mm to min. 182 mm e 257 mm
Paper weight 64 to 244 g/m
2
Trimming capacity 50 sheets (80 g/m
2
) e 2, or 49 sheets (80 g/m
2
) + 1
(200 g/m
2
) e 2
Straight delivery Paper size Standard: SRA3 w, A3 w, B4 w, SRA4 w/v, A4 w/v,
B5 w/v, A5 w/v, B6 w, Foolscap, A6 w, 13 e 19 w,
12 e 18 w, 11 e 17 w, 8.5 e 14 w, 8.5 e 11 w/v,
5.5 e 8.5 w/v, 9 e 11 v
Custom: max. 330 mm e 487 mm to min. 100 mm e 148 mm
Tab Paper (only with the tab side ahead in output direction)
Paper weight 64 to 350 g/m 2
Weight Approx. 280 kg
Power source 100 to 240 VAC, 5 VDC (supplied from Relay Unit RU-508)
Power consumption 270 W
