bizhub PRESS C8000/e 14-9
14.3 Feeding Option Specifications 14
14.3.4 Post Inserter PI-502 (Equipped in Finisher FS-612)
14.3.5 Dehumidifier Heater HT-506
Name PI-502
Type Paper feeding equipment with separable torque limiter
Function Automatic Feed paper into the finisher on receiving a command from
the main body.
Manual Feed paper into the finisher on receiving a command manu-
ally sent from the control panel of the post inserter.
Paper sizes Upper tray Standard: A4 w/v, B5 w/v, A5 v, 8.5 e 11 w/v, 5.5 e 8.5 v
Custom: max. 216 mm e 297 mm to min. 182 mm e 139 mm
Lower tray Standard: A3 w, B4 w, SRA4 w, A4 w/v, B5 w/v, A5 v,
Foolscap, 12 e 18 w, 11 e 17 w, 8.5 e 14 w, 8.5 e 11 w/v,
5.5 e 8.5 v
Custom: max. 314 mm e 458 mm to min. 182 mm e 139 mm
Paper type Plain, Fine, Recycled
Paper weight 50 g/m 2 to 200 g/m 2
Stack capacity 200 sheets (80 g/m
2
) or within 30 mm thick for each of up-
per/lower tray
Dimensions 511 (W) e 620 (D) e 220 (H) mm
Weight Approx. 10.5 kg
Power source 24/5 VDC supplied from Relay Unit RU-508
Maximum power consumption 30 W or less
Name HT-506
Function Dehumidifier of fan heater type
Dimensions Dehumidifier fan unit + supply/exhaust air duct:
293 (W) e 336 (D) e 176 (H) mm
Power supply unit:
212 (W) e 106 (D) e 77 (H) mm
Weight Approx. 6 kg
Power source/requirements DC: 24 V, 5V
AC: 180 to 264 V (50/60Hz)
Power consumption DC: 6 W or less
AC: 384 W or less (per unit)
