bizhub PRESS C8000/e
9-81
9.11
[04 Density Balance Adjustment]
9
1
Press [Adjustment] on the Machine Screen to display the Adjustment Menu Screen.
2
Press [04 Density Balance Adjustment] and [02 Density Balance Data Reg/Del] in sequence.
The Density Balance Adjustment Data Register/Delete Screen will be displayed.
3
Select the row of the existing data to be edited.
4
Press [Manual Setting].
The Density Adjustment Manual Setting Screen will be displayed.
5
Select a color to be adjusted from [Yellow], [Magenta], [Cyan], and [Black].
6
Select either [All e 9 points] or [16 e 32 points].
7
Select the screen type on which the adjusted density balance should be reflected.
% Press [Screen] to display the Screen Selection Screen.
% Select the desired key.
% Press [OK].
NOTICE
The screen type cannot be changed if the data to be edited is the colorimetric data measured with spec-
trophotometer. [Screen] will appear grayed out to show inactivity.
8
For [All e 9 points] selected in step 6, enter the desired adjustment value in the following 9 points taken
out from 01 to 32 on the X-axis: [01], [05], [09], [13], [17], [21], [25], [29], [32].
For [16 e 32 points] selected in step 6, enter the adjustment value into your desired points selected from
a total of 512 points; 32 points in crosswise direction, and 16 points in feeding direction.
% Use [*] and [)] as needed to display the desired point on the X-axis.
% Pressing the top row of the X-axis selects all the column and allows you to enter the same value
collectively.
% Use [+/-] to specify the value to be positive or negative. Press [Clear] to set the value at 0.
% Press [Set].
9
Repeat steps 5 to 8 to adjust the density balance for all the desired colors.
% To clear the adjustment data, press [Clear Adj. Data]. All the adjustment values will return to 0.
NOTICE
Pressing [Clear Adj. Data] clears not only the adjustment values specified for the selected color, but also
those specified for any other colors. Please be careful with the use of this key.
10
Press [Print Mode].
The Print Mode Screen will be displayed.
