AT-S60 Management Software User’s Guide
Section II: Local and Telnet Management 89
Displaying Port Status
This section provides a procedure to display the status of a port. To
display port statistics, see Displaying Port Statistics on page 98.
To display the status of the ports on the switch, perform the following
procedure:
1. From the Main Menu, type 1 to select Port Menu.
The Port Menu is shown in Figure 25.
Figure 25 Port Menu
2. From the Port Menu, type 2 to select Port Status. The Port Status
Menu is shown in Figure 26.
Figure 26 Port Status Menu
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
Port Menu
1 - Port Configuration
2 - Port Status
3 - Port Statistics
4 - Port Trunking
5 - Port Mirroring
R - Return to Previous Menu
Enter your selection?
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
Port Status
Port Status Link Neg MDI/X Speed Duplex PVID Flow Ctl STP State Priority
-----------------------------------------------------------------------------------
1.1
Enabled Up Auto MDI 0010 Half 0001 Disabled Forwarding No
1.2 Enabled Up Auto MDI 0100 Full 0001 Disabled Forwarding No
1.3 Enabled Up Auto MDI 0100 Full 0001 Disabled Forwarding No
1.4 Enabled Up Auto MDI 0100 Full 0001 Disabled Forwarding No
1.5 Enabled Up Auto MDI 0010 Half 0001 Disabled Forwarding No
1.6 Enabled Up Auto MDI 0100 Full 0001 Disabled Forwarding No
1.7 Enabled Up Auto MDI 0100 Full 0001 Disabled Forwarding No
1.8 Enabled Up Auto MDI 0010 Half 0001 Disabled Forwarding No
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
