AT-S60 Management Software User’s Guide
Section II: Local and Telnet Management 237
The Configure MSTP Port Settings menu is shown in Figure 87.
Figure 87 Configure MSTP Port Settings Menu
4. Adjust the port settings as needed. The selections are described
below:
1 - Port Priority
This parameter is used as a tie breaker when two or more ports are
determined to have equal costs to the regional root bridge. The
range is 0 to 240 in increments of 16. The default value is 8 (priority
value 128). For a list of the increments, refer to Table 7, Port
Priority Value Increments on page 189.
2- Port Internal Path Cost
The port cost of the port if the port is connected to a bridge which
is part of the same MSTP region. The range is 0 to 200,000,000. The
default setting is Auto-detect, which sets port cost depending on
the speed of the port. Default values are 2,000,000 for 10 Mbps
ports, 200,000 for a 100 Mbps ports, and 20,000 for one gigabit
ports.
3- Port External Path Cost
The port cost of the port if the port is connected to a bridge which
is a member of another MSTP region or is running STP or RSTP. The
range is 0 to 200,000,000. The default setting is 200,000.
4 - Point-to-Point
This parameter defines whether the port is functioning as a point-
to-point port. For an explanation of this parameter, refer to Point-
to-Point Ports and Edge Ports on page 190.
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
Configure MSTP Port Settings
1 - Port Priority ............... 128
2 - Port Internal Path Cost ..... Auto Update
3 - Port External Path Cost ..... 200000
4 - Point-to-Point .............. Auto Detect
5 - Edge Port ................... Yes
C - Check Migration to RSTP on Selected Ports (MCHECK)
R - Return to Previous Menu
Enter your selection?
