AT-S60 Management Software User’s Guide
Section III: Security Features 407
the authentication server for verification, then the authentication server
informs the authenticator whether or not the authentication attempt
has succeeded. Consequently, PC A is either granted or denied access to
the LAN behind the switch.
Figure 141 Authenticator to Supplicant Configuration
Authenticator
Supplicant
Authenticator Server
LAN
PC A
Server A
Server B
Server C
Server D
8021X1_R
