AT-S60 Management Software User’s Guide
Section IV: Web Browser Management 487
Displaying the Port Trunks
This procedure allows you to view the port trunk settings using a web
browser management session.
To display the port trunks, perform the following procedure:
1. From the Home page, select Monitoring.
The Monitoring System page is displayed with the General tab
selected by default, as shown in Figure 157 on page 442.
2. Select the Layer 1 option.
The Layer 1 page is displayed with the Port Settings tab selected
by default, as shown in Figure 170 on page 471.
3. Select the Port Trunking tab.
The Port Trunking tab is shown in Figure 178.
Figure 178 Monitoring Layer 1 Page, Port Trunking Tab
