Chapter 18: IGMP Snooping
Section II: Local and Telnet Management 326
Configuring IGMP Snooping
To configure, enable, or disable IGMP snooping on the switch and to
configure IGMP snooping parameters, perform the following procedure:
1. From the Main Menu, type 5 to select System Menu.
The System Menu is shown in Figure 5 on page 47.
2. From the System Menu, type 1 to select Configure System.
The Configure System Menu is shown in Figure 9 on page 52.
3. From the Configure System menu, type 1 to select Configure System
Software.
The Configure System Software Menu is shown in Figure 10 on
page 53.
4. From the Configure System Software menu, type 7 to select
Configure IGMP Snooping.
The IGMP Snooping Configuration menu is shown in Figure 116.
Figure 116 Configure IGMP Snooping Menu
Note
Options 6 and 7 in the menu are discussed later in this chapter.
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 01-Jan-2003
Configure IGMP Snooping
1 - IGMP Snooping Status ......... Disabled
2 - Multicast Host Topology ...... Single-Host/Port (Edge)
3 - Host/Router Timeout Interval . 260 seconds
4 - Maximum Multicast Groups ..... 256
5 - Multicast Router Ports Mode .. Auto Detect
6 - View Multicast Hosts List
7 - View Multicast Router List
R - Return to Previous Menu
Enter your selection:
