Chapter 12: STP, RSTP, and MSTP
Section II: Local and Telnet Management 228
The MSTP Menu is shown in Figure 82.
Figure 82 MSTP Menu
Menu selections 1 to 8 are described below. Selections C, M, V, and
P are described in later sections in this chapter.
3. Adjust the MSTP settings as needed. The selections are described
below.
1 - Force Version
This selection determines whether the bridge operates with MSTP
or in an STP-compatible mode. If you select MSTP, the bridge
operates all ports in MSTP, except for those ports that receive STP
or RSTP BPDU packets. If you select Force STP Compatible, the
bridge uses its MSTP parameter settings, but sends only STP BPDU
packets from the ports.
2 - Hello Time
The time interval between generating and sending configuration
messages by the bridge. The range of this parameter is 1 to 10
seconds. The default is 2 seconds. This value is active only if the
bridge is selected as the root bridge of the network.
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
MSTP Menu
1 - Force Version .......... MSTP
2 - Hello Time ............. 2
3 - Forwarding Delay ....... 15
4 - Max Age ................ 20
5 - Max Hops ............... 20
6 - Configuration Name .....
7 - Revision Level ......... 0
8 - Bridge Identifier ...... 00:30:24:1E:EE:11
C - CIST Menu
M - MSTI Menu
V - VLAN-MSTI Association Menu
P - MSTP Port Parameters
R - Return to Previous Menu
Enter your selection?
