Chapter 12: STP, RSTP, and MSTP
Section II: Local and Telnet Management 236
3. A prompt similar to the following is displayed:
Enter the list of VLANs:
4. Enter the VLAN ID of the virtual LAN that you want to associate with
the MSTI ID. You can enter more than one VLAN at a time (for
example, 2,4,7) (To view VIDs, refer to Displaying VLANs on page
257.)
The VLANs already associated with the MSTI ID are removed when
the new VLANs are added. The removed VLANs are returned to
CIST.
5. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Configuring
MSTP Port
Settings
To configure a port’s MSTP parameters, perform the following
procedure:
1. From the MSTP Menu, type P to select MSTP Port Parameters.
The MSTP Port Parameters menu is shown in Figure 86.
Figure 86 MSTP Port Parameters Menu
2. Type 1 to select Configure MSTP Port Settings.
The following prompt is displayed:
Enter port-list:
3. Enter the port to configure. For instructions on how to specify port
numbers, refer to Specifying Ports on page 31.
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
MSTP Port Parameters
1 - Configure MSTP Port Settings
2 - Display MSTP Port Configuration
3 - Display MSTP Port State
R - Return to Previous Menu
Enter your selection?
