Chapter 4: SNMP Community Strings
Section II: Local and Telnet Management 78
Displaying a SNMP Community
Use the following procedure to display the attributes of a SNMP
community.
1. From the Main Menu, type 5 to select System Menu.
The System Menu is shown in Figure 5 on page 47.
2. From the System Menu, type 1 to select Configure System.
The Configure System Menu is shown in Figure 9 on page 52.
3. From the Configure System menu, type 1 to select Configure System
Software.
The Configure System Software Menu is shown in Figure 10 on
page 53.
4. From the Configure System Software menu, type 8 - Configure SNMP.
The Configure SNMP menu is shown in Figure 17 on page 70.
5. Select 4 - Display SNMP Community to display the attributes of an
SNMP community.
The Display SNMP Community menu is shown in Figure 20.
Figure 20 Display SNMP Community Menu
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
Display SNMP Community
Community Name Access Mode Status OpenAcc Manager IP Address Trap Receiver IP
====================================================================================
Private125 Read|Write Enabled No 147.41.11.30 147.45.16.70
147.45.16.80 147.45.16.80
PublicATI78 Read Only Enabled No 147.41.11.12 147.42.22.22
147.44.16.86 147.45.16.86
147.45.16.88 147.45.16.88
147.45.16.90 147.45.16.90
HighSchool2 Read|Write Enabled No 147.45.10.80 147.45.10.80
U - Update Display
R - Return to Previous Menu
Enter your selection?
