Chapter 36: MAC Address Table
Section IV: Web Browser Management 544
Adding Static Unicast and Multicast MAC Addresses
This section contains the procedure for assigning a static unicast or
multicast address to ports on the switch. You can assign up to 255 static
MAC addresses per port.
Note
When you add a static multicast address you must assign the
address to all ports on the switch that belong to the multicast group.
This includes the ports connected to the multicast application
server and the host nodes. Failure to assign the address to all ports
in the group prevents the multicast packets from reaching all
appropriate nodes.
To add a static unicast or multicast address to the MAC address table,
perform the following procedure:
1. From the Home Page, select Configuration.
The Configuration System page is displayed with the General tab
selected by default, as shown in Figure 155 on page 434.
2. From the Configuration menu, select the Layer 2 option.
The Layer 2 page is displayed with the MAC Address tab selected
by default, as shown in Figure 204 on page 541.
3. Click Add.
The Add MAC Address page is shown in Figure 206.
Figure 206 Add MAC Address Page
4. In the MAC Address field, enter the new static unicast or multicast
MAC address.
