Chapter 29: Port Parameters
Section IV: Web Browser Management 466
Configuring Port Parameters
This procedure describes how to configure one or more ports on an
AT-8400 switch. It is important to note that when you select multiple
ports for configuration, you are making the same configuration changes
on all of the ports.
To configure the parameter settings for a port or ports on a switch,
perform the following procedure:
1. From the Home Page, select Configuration.
The Configuration System page is displayed with the General tab
selected by default, as shown in Figure 155 on page 434.
2. Select the Layer 1 option.
The Layer 1 page is displayed with the Port Settings tab selected
by default, as shown in Figure 168.
Figure 168 Configuration Layer 1 Page, Port Settings Tab
This page displays a graphical image of the front of the switch.
Ports with a valid link to an end node are green.
3. Click on the port or ports that you want to configure. After you click
on a port, it turns white. (To deselect a port, click it again.)
