AT-S60 Management Software User’s Guide
Section IV: Web Browser Management 527
Displaying VLANs
To display all the existing VLANs on a switch, perform the following
procedure:
1. From the Home page, select Monitoring.
The Monitoring System page is displayed with the General tab
selected by default, as shown in Figure 157 on page 442.
2. Select the Layer 2 option.
The Monitoring Layer 2 page is displayed with the MAC Address
tab selected by default, as shown Figure 204 on page 541.
3. Select the VLAN tab.
The Monitoring VLAN tab is shown in Figure 198.
Figure 198 Monitoring Layer 2 Page, VLAN Tab
The VLANs are displayed in a table. The columns in the table are:
VLAN ID
VID value for the VLAN.
Name
Name of the VLAN.
