AT-S60 Management Software User’s Guide
Section IV: Web Browser Management 573
Displaying 802.1x Port Access Information
To view host nodes and multicast routers, perform the following
procedure:
1. From the Home Page, select Monitoring.
The Monitoring System page is displayed with the General tab
shown by default.
2. Select the Layer 1 option.
The Layer 1 page is displayed with the Port Settings tab shown by
default.
3. Select the 802.1x Port Access tab.
The 802.1x Port Access tab is displayed as shown in Figure 222.
Figure 222 Monitoring Layer 1 Page, 802.1x Port Access Tab
4. To see the status of the port, click once the port or ports to select it
and click Status.
Note
All the ports must have the same port role (authenticator or
supplicant) to view the status of multiple ports.
