AT-S60 Management Software User’s Guide
Section II: Local and Telnet Management 201
The STP Port Parameters Menu is shown in Figure 69.
Figure 69 STP Port Parameters Menu
3. Type 1 to select Configure STP Port Settings.
The following prompt is displayed:
Enter port-list:
4. Enter the port to configure. For instructions on how to specify port
numbers, refer to Specifying Ports on page 31.
The STP Port Configuration menu is shown in Figure 70.
Figure 70 Configure STP Port Settings Menu
5. Adjust the settings as desired. The parameters are described below.
1 - Port Priority
This parameter is used as a tie breaker when two or more ports are
determined to have equal costs to the root bridge. The range is 0
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
STP Port Parameters
1 - Configure STP Port Settings
2 - Display STP Port Configuration
R - Return to Previous Menu
Enter your selection?
Allied Telesyn AT-8400 Series - ATS60 V2.0.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2003
Configure STP Port Settings
Configuring Ports 1.4
1 - Port Priority ...... 128
2 - Port Cost .......... Automatic-Update
R - Return to Previous Menu
Enter your selection?
