Chapter 11: File Downloads and Uploads
Section II: Local and Telnet Management 160
5. If the new image file differs from the existing one, the following
message is displayed:
For the local management session:
Switch is about to reboot. Do you want to proceed?
[Yes/No]
For the Telnet management session:
Remote access will be lost. Do you want to continue?
[Yes/No]
6. Type N if you do not want to activate the new image file.
The Downloads & Uploads menu is displayed, as shown in Figure
45 on page 154.
7. Type Y to activate the new image file and reset the switch.
Note
If you type Y and are using a Telnet management session for this
procedure, the Telnet session terminates. Allow at least two minutes
for the process to complete before you restart the Telnet
management session.
The switch now decompresses and initializes the software, a
process that takes less than two minutes to complete. After the
management software is initialized, you can press any key to start
a local management session, or restart the Telnet management
session to display the login prompt.
Note
Do not interrupt the decompression and initialization process. Do
not manually reboot the switch. The switch automatically reboots as
part of the initialization process.
