6. Configure the tengigabitethernet port 102/3/2 as the tracking port for interface ve 10, with a track

priority of 20.

sw102(config-vrrp-extended-group-1)# track te 102/3/2 priority 20

7. Configure an IP address for the virtual router.

sw102(config-vrrp-extended-group-1)# virtual-ip 192.53.5.254

NOTE
(For VRRP-E only) The address you enter with the virtual-ip command cannot be the same as a real
IP address configured on the interface.

Configuring Router 2 as master for second virtual router group

1. Enter the rbridge-id command, using the RBridge ID (which has an asterisk next to it when you run a

do show vcs command).

sw102(config)# rbridge-id 102

2. Configure the Ve interface link for Router 2.

sw102(config-rbridge-id-102)# int ve 15

3. Configure the IP address of the Ve link for Router 2.

sw102(conf-Ve-15)# ip address 192.54.6.3/24

4. Assign Router 2 to the group called Group 2.

sw102(conf-Ve-15)# vrrp-extended-group 2

5. Configure the tengigabitethernet port 102/2/4 as the tracking port for interface ve 15, with a track

priority of 20.

sw102(config-vrrp-extended-group-2)# track te 102/2/4 priority 20

6. To configure Router 2 as the master, set the priority to a value higher than the default (which is 100):.

sw102(config-vrrp-extended-group-2)# priority 110

7. Configure an IP address for the virtual router.

sw101(config-vrrp-extended-group-2)# virtual-ip 192.53.6.253

NOTE
(For VRRP-E only) The address you enter with the virtual-ip command cannot be the same as a real
IP address configured on the interface.

Configuring Router 2 as master for second virtual router group
