Applying the DSCP-to-traffic-class mapping to an interface

To activate a DSCP-to-Traffic Class mapping, perform the following steps from privileged EXEC mode.

1. Enter global configuration mode.

switch# configure terminal

2. Specify the Ethernet interface.

The gigabitethernet rbridge-id/slot/port operand is used only for the Brocade VDX 6710, Brocade
VDX 8770-4, and Brocade VDX 8770-8.

switch(config)# interface tengigabitethernet 1/1/2

3. Activate the DSCP-to-Traffic-Class mapping. In this case, "test" is the map name.

switch(conf-if-te-1/1/2)# qos dscp-traffic-class test

NOTE
To deactivate a DSCP-to-Traffic-Class map from an interface, enter no qos dscp-traffic-class
name.

4. Return to privileged EXEC mode.

switch(conf-if-te-1/1/2)# end

5. Enter the copy command to save the running-config file to the startup-config file.

switch# copy running-config startup-config

Verifying the DSCP-to-Traffic-Class mapping

To verify a DSCP-to-Traffic-Class mapping, you can use one or both of the following options from
global configuration mode.

• Verify the DSCP-Traffic-Class mapping for specific map by using the do show qos maps dscp-

traffic-class command and specifying a map name.

switch(config)# do show qos maps dscp-traffic-class test

• Verify all DSCP-Traffic-Class mapping with the just the do show qos maps command with the

dscp-traffic-class parameter only.

switch(config)# do show qos maps dscp-traffic-class

.

• Verify DSCP-to-Traffic-Class mapping for an interface by using the show qos interface command

and specifying the interface.

switch(config)# show qos interface te 1/1/2

Configuring congestion control

Refer also to

Congestion control

on page 472.

Changing the multicast tail-drop threshold

To change the tail drop threshold, perform the following steps from privileged EXEC mode.

1. Enter global configuration mode.

switch# configure terminal

2. Change the tail drop threshold for each multicast traffic class. In this example, a threshold of 1000

packets is used.

switch(config)# qos rcv-queue multicast threshold 1000 1000 1000 1000 1000 1000

1000 1000

3. Return to privileged EXEC mode.

switch(config)# end

4. Enter the copy command to save the running-config file to the startup-config file.

switch# copy running-config startup-config
