MIB access levels

TABLE 19

Access level

Description

not accessible

You cannot read or write to this variable.

read create

Specifies a tabular object that can be read, modified, or created as a new row in a
table.

read only - Public

You can only monitor information.

read-write - Private

You can read or modify this variable.

accessible-to-notify

You can read this information only through traps.

Brocade MIBs

The Brocade MIB is a set of variables that are private extensions to the Internet standard MIB-II. The
Brocade agents support many other Internet-standard MIBs. These standard MIBs are defined in RFC
publications. To find specific MIB information, examine the Brocade proprietary MIB structure and the
standard RFC MIBs supported by Brocade.

Brocade MIB files

The Brocade MIB files are as follows:

• BRCD_NOS_PRODUCTS.mib
• BROCADE-PRODUCTS-MIB.mib
• BROCADE-REG-MIB.mib
• BRCD_TC.mib
• SWBase.mib
• Resource.mib
• System.mib
• FA.mib
• HA.mib
• FOUNDRY-SN-NOTIFICATION.mib

Agent Capability MIBs

In SNMP, capability MIBs provide the implementation details for the associated MIBs. These MIBs,
called AGENT-CAPABILITY MIBs, list supported conformance groups and any deviations from the
MIBs as implemented in the associated software version. The following lists the Brocade supported
capability MIBs.

Agent Capabilities

TABLE 20

Capability MIBs

Description

BROCADE-IEEE8021-PAE-CAPABILITY-MIB

Provides the implementation details for the IEEE8021-
PAE-MIB

BROCADE-IEEE8023-LAG-CAPABILITY-MIB

Provides the implementation details for the IEEE8023-
LAG-MIB

BROCADE-LLDP-CAPABILITY-MIB

Provides the implementation details for the LLDP-MIB
