Configuring transport VF classification to a trunk interface

The following example command sequence illustrates the configuration of VF classification to a trunk
interface.

switch(config)# interface TenGigabitEthernet 1/0/1

switch(conf-if-te-1/0/1)# switchport

switch(conf-if-te-1/0/1)# switchport mode trunk

switch(conf-if-te-1/0/1)# switchport trunk allowed vlan add 6000 ctag 600-610

Creating a default VLAN with a transport VF to a trunk interface

The following example command sequence illustrates the configuration of a default VLAN with a
transport VF to a trunk interface.

switch(config)# interface TenGigabitEthernet 1/0/1

switch(conf-if-te-1/0/1)# switchport

switch(conf-if-te-1/0/1)# switchport mode trunk

switch(conf-if-te-1/0/1)# switchport trunk default-vlan 7000

Configuring a native VLAN in regular VLAN trunk mode

The following examples illustrate the configuration of a native VLAN in regular VLAN trunk mode, where
the default native VLAN 1 exists.

The following native VLAN commands are supported in this trunk mode:

switchport trunk tag native-vlan
switchport trunk native-vlan

1. Create native VLAN 10.

NOTE
VLAN 1 is the default VLAN in this mode.

switch(config)# interface te 2/1/1

switch(config-if-te-2/1/1)# switchport mode trunk

switch(config-if-te-2/1/1)# switchport trunk native-vlan 10

2. Configure untagged native VLAN (service VF) 5000 and transport VLAN (transport VF) 6000, and

make VLAN 7000 the default VLAN.

switch(config)# interface te 2/1/1

switch(config-if-te-2/1/1)# switchport mode trunk

switch(config-if-te-2/1/1)# no switchport trunk tag native

switch(config-if-te-2/1/1)# switchport trunk native-vlan 5000

switch(config-if-te-2/1/1)# switchport trunk allow vlan add 6000 ctag 100-200

switch(config-if-te-2/1/1)# switchport trunk default-vlan 7000

3. Configure transport VLAN 6000 to accept the C-TAG range 100 through 200, as well as tagged or

untagged native VLAN traffic.

switch(config)# interface te 2/1/1

switch(config-if-te-2/1/1)# switchport mode trunk

switch(config-if-te-2/1/1)# no switchport trunk tag native

switch(config-if-te-2/1/1)# switchport trunk native-vlan 6000 ctag 10

switch(config-if-te-2/1/1)# switchport trunk allow vlan add 6000 ctag 100-200
