NOTE
(For VRRP-E only) The address you enter with the virtual-ip command cannot be the same as a
real IP address configured on the interface.

8. To configure Router 1 as the master, set the priority to a value higher than the default (which is

100).

sw101(config-vrrp-group-1)# priority 110

Configuring Router 1 as backup for second virtual router group

1. Enter the rbridge-id command, using the RBridge ID (which has an asterisk next to it when you run

a do show vcs command).

sw101(config)# rbridge-id 101

2. Configure the Ve interface link for Router 1.

sw101(config-rbridge-id-101)# int ve 15

3. Configure the IP address of the Ve link for router 1.

sw101(config-Ve-15)# ip address 192.54.6.2/24

4. Assign Router 1 to a group called Group 2.

sw101(config-Ve-15)# vrrp-extended-group 2

5. Configure the tengigabitethernet port 101/2/4 as the tracking port for the interface ve 10, with a

track priority of 20.

sw101(config-vrrp-extended-group-2)# track te 101/2/4 priority 20

6. Configure an IP address for the virtual router.

sw101(config-vrrp-extended-group-2)# virtual-ip 192.53.6.253

NOTE
(For VRRP-E only) The address you enter with the virtual-ip command cannot be the same as a
real IP address configured on the interface.

Configuring Router 2 as backup for first virtual router group

Make sure that VCS is enabled and then perform these steps:

1. Enter the rbridge-id command, using the RBridge ID (which has an asterisk next to it when you run

a do show vcs command).

sw102(config)# rbridge-id 102

2. Configure the VRRP protocol globally.

sw102(config-rbridge-id-102)# protocol vrrp

3. Configure the Ve interface link for Router 2.

sw102(config-rbridge-id-102)# int ve 10

4. Configure the IP address of the Ve link for Router 2.

sw102(conf-Ve-10)# ip address 192.53.5.3/24

5. Assign Router 2 to the group called Group 1.

sw102(conf-Ve-10)# vrrp-extended-group 1

Configuring Router 1 as backup for second virtual router group
