172
INTELLIGENT ACTUATOR
Chapter 4 Commands
2.
Explanation
of
Commands
z ISXX (Compare strings)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Optional Optional ISXX
Column
number
Column
number,
character
literal
CP
[Function] Compare the character strings in the columns specified in operands 1 and 2, and proceed to
the next step if the condition is satisfied.
If the condition is not satisfied, the program will proceed to the step next to the corresponding
ELSE command, if any, or to the step next to the corresponding EDIF command.
Comparison will be performed for the length set by a SLEN command.
If a character literal is specified in operand 2, comparison will be performed for the entire
length of the literal.
If the input condition is not satisfied and the ISXX command is not executed, the program will
proceed to the step next to the EDIF.
A maximum of 15 nests are supported when IFXX and DWXX are combined.
ISXX
EQ Operand 1 = Operand 2
NE Operand 1 z Operand 2
[Example 1] VEL 100 Set the speed to 100 mm/sec.
SCPY 10 ‘GOFD’ (Move
forward)
SCPY 14 ‘GOBK’ (Move
backward)
LET 1 5
LET 2 14
600 SLEN 4 Set the number of comparing characters to 4.
ISEQ 1 ‘1AXS’ (Axis 1) Select an axis.
ISEQ 5 10 Select a moving direction.
JFWN 01 5 Move axis 1 forward.
ELSE
JBWN 01 5 Move axis 1 backward.
EDIF
ELSE
ISNE *1 *2 Select a moving direction.
JFWN 10 5 Move axis 2 backward.
ELSE
JBWN 10 5 Move axis 2 forward.
EDIF
EDIF
Jog by selecting axis 1/axis 2 by columns 1 to 4 and forward/backward by columns 5
to 8.
Nothing will happen if flag 600 is OFF, in which case the program will proceed to the
step next to the last EDIF.
If columns 1 to 8 contain the following data, axis 1 will be moved forward.
1 2 3 4 5 6 7 8
1A XS GO FD
(Note) Using a GOTO command to branch out of or into an ISXX-EDIF syntax is prohibited.
